Base Materials: SACM645,SCM440,SKD61 Treatment: Nitrided & Bimetallic Hardness: HRC55-HRC70
Tech Introduction:
⁕Bimetallic Process :
Basis Materials: SACM645, SACM440, SKD61, SKD11
Hardness: 53-58 HRC
Coating Thickness: 1.5-2.0mm
Allication: Plastic PE/PVC...Recycling ≤2 Times, Plastics With Glass Fiber≤35%
Wear resistance: ★★★★★
Corrosion resistance: ★★★
Basis Materials: SACM645, SACM440, SKD61, SKD11
Chrome Thickness: 0.02-0.08mm
Hardness of Chrome: >700 HV
Finish Grade: Ra ≤0.4
Allication: PVC and other high corrosive plastics
Wear resistance: ★★
Corrosion resistance: ★★★★★
⁕Full Hardened Process:
Basis Materials: DC53, D2, M2, SKD61, SKD11 ...
Chemical Composition: C, Si, Cr, Mn, Mo, V, Ni
Hardness: SKD61(HRC56-58), DC53( 62-63 HRC)
Application: PP PA LCP, POM, PPA, PBT, PC, PPS, PEI, PEEK with Glass Fiber ≤50%
Wear resistance: ★★★★★
Corrosion resistance: ★★★★★
Shipment:
1. The delivery time of our screw barrel is usually 20-25 days after drawings are confirmed.
2. Can send Faster air shipment by TNT, SF, FedEx, DHL, UPS, EMS and etc.
D25 screw barrel set for PET extrusion process
Haixiong Machine HXM1250T-130mm Bimetallic Screw
Haida Machine HDJS1250T-D130 Bimetallic Screw ba
